Ortofon
Ortofon Hi-Fi 20 Replacement Stylus
DenmarkSTYLUS 20
The Ortofon Stylus 20 needle stylus is the standard replacement stylus for the Ortofon OM-20 OM20 phono cartridge and its older siblings.
- Replacement Stylus for Ortofon OM and Super OM series
- Will fit the following Ortofon cartridges: all Super OM, OM, OMB, OMP, TM, Concorde STD
- Recommended for following cartridges: Super OM 20, OM 20, OMP 20, OMB 20, LM 20, Concorde 20, LM 20H, TM 20U, TM 20H
- Stylus Type – Nude Elliptical
- Recommended tracking force is 1.5g
Frequency response
20-20.000 Hz + 2 / - 3 dB
Tracking ability at 315Hz at recommended tracking force *)
70 µm
Compliance, dynamic, lateral
25 µm/mN
Stylus type
Nude Elliptical
Stylus tip radius
r/R 8/18 µm
Tracking force range
1.25-1.75 g (12.5-17.5 mN)
Tracking force, recommended
1.5 g (15 mN)
Tracking angle
20°
Stylus colour
Black
Recommended for following cartridges: Super OM 20, OM 20, OMP 20, OMB 20, LM 20, Concorde 20, LM 20H, TM 20U, TM 20H
