GigaWatt PC-3 EVO+ Premium Power Line Conditioner

PC-3 EVO+ Premium Power Line Conditioner

PC-3 EVO+ is a technologically advanced, new generation power conditioner, designed to power and protect audio-video systems of Hi-Fi and High-End class.

FEATURES

• possibility of connecting 6 devices
• ideal also for high-end power amplifiers
• significantly improves sound quality in every aspect does not limit the dynamics of the system
• optimally filters the current in 3 independent sections
• effectively protects equipment from the effects of overvoltage and short circuits
• continuously monitors the voltage in the network (display can be turned off)
• built-in DC-Blocker - reduces the adverse effects of DC components in the network PowerSync PLUS power cord included in the set

TECHNICAL SOLUTIONS

The design of the PC-3 EVD+ is based on a unique eight-stage filter architecture using the most advanced, uncompromising components. The conditioner is equipped with three autonomous filtering branches, serving separate three sections, consisting of four outlets each. This allows isolation of individual loads from mutual interference generated by connected devices using a common power line.

The innovative two-stage power distribution system is based on massive distribution rails made of OFHC C10100 oxygen-free copper bars of 99997% purity. The first stage allows for lossless and even voltage distribution to the individual filter branches. The second stage delivers current directly to each quart of output sockets. The company's semi-multistrand conductors with enlarged cross-section, made of silver-plated oxygen-free copper insulated with Teflon, are responsible for the transmission of current between the individual modules. These solutions ensure even and stable power distribution regardless of the load on the individual outputs of the conditioner.

The company's anti-interference capacitors are responsible for the essential filtering of interference, and are manufactured to GigaWatt's strict specifications. Surge protection of the conditioner is provided by high-end elements with increased absorption and aging resistance. A two-pole hydraulic-magnetic circuit breaker custom manufactured to GigaWatt specifications was used as overload protection. This component acts as a circuit to control the value of current flowing through the internal circuits and as the main circuit breaker of the conditioner. Lossless current transmission is ensured by printed circuits with extremely wide conductive pathe made of silver-plated copper of extreme thickness that is up to fifteen times thicker than standard PCBs. Interference suppression is provided by RLC-type filtering blocks, built using, among other things, the company's Audio Grade filter capacitors and filters based on cores with significantly lower power losses, enabling a significant increase in the value of current flowing through the filter.

Standard equipment of the PC-3 EVO+ is the DC Offset Blocker - a circuit that eliminates the unwanted DC component of the electric grid. It allows to effectively eliminate this phenomenon, without causing compression or any other negative effect on the sound.

The design of the conditioner's internal components allows it to handle a momentary load of BOA! To ensure the highest possible

OPTIONAL EQUIPMENT

• Personalized voltage display color

• Power cords - higher models: LC-2 EVO, PowerSync ULTRA LS-1EVD+

• Rolling-Ball Isolation System feet

• Output sockets with integrated electric shock shutters (EU Schuko version only)
