RCD-1572MKII

The RCD-1572MKII follows Rotel’s proud tradition of delivering award-winning CD players since 1989 with accurate reproduction of the audio, an exceptional sense of space, accurate frequency response and an ultra-low noise floor.

The RCD-1572MKII is both classic and refined ready for your music collection delivering stunning detail and extraordinary clarity.

Engineered with care.

Product Description

The RCD-1572MKII follows Rotel’s proud tradition of delivering award winning CD players since 1989 supporting the over 200 billion CDs sold in the market with authentic, genuine detail delivering an exceptional sense of space and depth.

Utilizing an ultra-low noise in-house manufactured toroidal transformer the RCD-1572MKII’s circuits are electrically and physically isolated removing unwanted distortion and lowering the noise floor.

A premium Texas Instruments 32-bit DAC delivers exceptional frequency response to fully balanced differential XLR Balanced, RCA and coaxial digital outputs.

The RCD-1572MKII is both classic and refined ready for your music collection delivering stunning detail and extraordinary clarity.

Dimensions (W × H × D)

431 × 104 × 320mm
17" × 4" × 12.6"

Front Panel Height

2U / 88.1mm (3.5")

Power Requirements

120V, 60Hz

Power Consumption

15W

Standby Power Consumption

<0.5W

Net Weight

7.34kg (16.18lbs.)

Total Harmonic Distortion (THD)

0.0035% @ 1kHz

Frequency Response

20Hz - 20kHz, 0 ±0.5dB

S/N Ratio (IHF "A" Weighted)

>118dB

Dynamic Range

>99dB

Digital to Analog Converters

Texas Instruments

Channel Balance

± 0.5dB

Channel Separation

>118dB @ 10kHz

Analog Output Level

Unbalanced (RCA): 2.2V

Balanced (XLR): 4.5V

Digital Output

0.5V, Peak to Peak

Analog Output Impedance

Unbalanced (RCA): 100Ω

Balanced (XLR): 200Ω

Load Impedance

75Ω
