THOR
ALPHA FIG8
POWER PROTECTION AND FILTRATION

ALPHA FIG8 is the affordable way to have power protection for your most valuable electrical equipment. The new slimline design now means you can have surge protection and filtration anywhere.
ALPHA FIG8 is the latest addition to the Thor Technologies product range and includes newly developed Mains Super Filter (MSF) technology.
The MSF is aimed at ensuring only the cleanest power isdelivered to your investment. This benefit means dirty poweris not robbing your connected equipment of its performance.The effects of unwanted dirty power or interference is reducedor eliminated.
Now including Flameproof MOV
Flameproof MOV ensures the main protection componentswill not catch fire while protecting from dangerous surges.The choice of Flameproof components and the added flameretardant housing safeguards ensures your home and familywill always be safe.

TV Mountable
The ALPHA FIG8’s slimline design enables it to be installed on a TV mount bracket, so it is out of sight.
Please note
The ALPHA FIG8 is used in conjunction with your existing Figure 8 Cable or Manufacturers supplied Figure 8 Cable.
Features
- INLINE PROTECTED OUTLET
- FIG 8 CONNECTOR
- SLIMLINE DESIGN
- ALARM BUZZER DETECTS IF SURGE CIRCUIT IS DAMAGED
- FLAME PROOF MOV
- POWER LED
- 600mm CABLE LENGTH
- FLAME RETARDANT HOUSING
- 100K CONNECTED EQUIPMENT WARRANTY
- 6 YEAR REPLACEMENT WARRANTY
Protects
- 4K/8K TVS
- COMPUTERS
- GAMING CONSOLES
- APPLIANCES
- SEWING MACHINES

1 - Inline protected outlet
2 - Power LED
3 - Alarm buzzer which detectsif a surge circuit is damaged
4 - Flame proof MOV
5 - Flame retardant housing
6 - Figure 8 connector
Inside the Brain
The MSF, Mains Super Filter technology, is aimed at ensuring only the cleanest power is delivered to your investment. This benefit means dirty power is not robbing your connected equipment of its performance. The effects of unwanted dirty power or interference is reduced or eliminated.
Videos
| Model | A1T |
| Product Dimensions | 81mm (L) × 61mm (W) × 31mm (H) |
| Supply Voltage | 240V AC / 50Hz |
| Maximum Current Rating | 2.5A / 600W (VA) |
| Clamping / Let Through Voltage | 510V AC |
| Reaction Time | Less than 1 nanosecond |
| Maximum Energy Dissipation | 2115 Joules (equivalent to 705 Joules using UL1449 standard) |
| Protection Modes | Active/Neutral, Active/Earth, Neutral/Earth |
| Total Protected AC Outlets | 1 |
| Earth Potential Rise Protection | Yes |
| Earth Leakage Range | Less than 1 milliamp |
| Operating Conditions | Indoor / AC mains |
| Operating Temperature Range | -10°C to +60°C |
| Cable Length | 600mm |
