D1/45 – 7 Way Surge Protector with Better Filtration
SMART TECHNOLOGY POWER PROTECTION AND FILTRATION
SmartFilter 7 is a popular board because of its slimline profile. The SmartBrain passive filter adds to the industry leading protection capability offering an all round solution.

Features
- 7 PROTECTED OUTLETS
- DATA/VOICE PROTECTION
- 1.2M CABLE LENGTH
- FIRE RETARDANT
Protects
- OLED/LCD TV
- HIFI AND HOME THEATRE
- ACTIVE/PASSIVE SPEAKERS
- COMPUTERS
- PRINTERS AND SCANNERS

1- RJ 45 data protection (1 in and 1 out)
2 - Single Bank (7 outlets): Surge protection
and filtering
3 - Resettable safety 10 amp circuit breaker

SMART BRAIN
The Thor SmartBrain not only protects from surges, it also filters and cleans electrical frequency noise to give you unbeatabe sound and video quality. Improves performance in all types of computers too.
Inside the Brain
SmartBrain entry level filter is a passive technology. Managing to cover a more comprehensive range of shielding to like competitors by “cleaning” a wider range of unwanted frequency noise. The filter works both ways. Stopping noise from robbing equipment performance as well as connected devices’ noise contaminating power.
Videos
| Model No. | D1/45B |
| Product Dimensions | 470mm (L) × 33mm (H) × 75mm (W) |
| Supply Voltage | 240 V AC, 50 Hz |
| Maximum Current Rating | 10 amps / 2400 W (VA) |
| Clamping Voltage | 300 V AC |
| Reaction Time | Less than 1 nanosecond |
| Maximum Transient Spike Impulse Current | 156,000 amps (equivalent to 39,000 amps using UL1449 standard) |
| Maximum Energy Dissipation | 4588 Joules (equivalent to 1550 Joules using UL1449 standard) |
| Protection Modes | Active/Neutral, Active/Earth, Neutral/Earth (all 7 outlets protect on all 3 conductors) |
| Noise Reduction Filter Type | EMI / RFI |
| Total Number of Protected AC Outlets | 7 |
| RJ45 Data Protection | 1 in / 1 out |
| Earth Potential Rise Protection | Yes |
| Earth Leakage Range | Less than 1 milliamp |
| Operating Temperatures | -10°C to +60°C |
| Cable Length | 1.2 m |
