Meridian DSP7200 HC Special Edition Centre Channel Loudspeaker (single)
Meridian DSP7200 HC Special Edition Centre Channel Loudspeaker (single)
Black
22 Saint Kilda Road
22 Saint Kilda Road
Suite 2.02
St Kilda VIC 3182
Australia
Country of origin: United Kingdom
Contact Geoff for Additional Colour Options
Reference
Special Edition DSP7200HC
Perfect for movies and music, the Special Edition DSP7200HC is an ideal partner for both Special Edition DSP7200 and Special Edition DSP8000 in a multi-channel system.
The SE DSP7200HC is designed for mounting under a large-screen TV, behind an acoustically-transparent projection screen and in systems that include Meridian free-standing or in-wall loudspeakers.
The Special Edition DSP7200HC provides sound that is incredibly lifelike in scale and tone. This horizontal centre-channel loudspeaker offers Enhanced Bass Alignment that corrects the delays inherent on low frequencies, resulting in a sweeter, more natural sound. Our unique Centre Elevation technology allows the Special Edition DSP7200HC to be placed below the screen while having its sound image match perfectly with the on-screen action, creating an immersive movie experience.
Finishes
Perfect for movies or music, the Special Edition DSP7200SE HC is the ideal companion for both a pair of Special Edition DSP7200 or Special Edition DSP8000 loudspeakers in a multi-channel system. The DSP7200SE HC provides sound that is incredibly lifelike, in scale and tone. The horizontal centre channel enables a stunningly effective home theatre set-up, while also providing seamless sound staging for music in Trifield. Finished as standard in a piano lacquer black, the Special Edition Range is also available in any of the 270 Meridian Select colours. The range offers a choice of full range floor standing or horizontal centre channel options, for audio or home cinema solutions.
Image Elevation
Image Elevation psychoacoustically raises the sound image to the centre of a screen – where the listener would expect to hear it from.
Bespoke Signal Mapping
Meridian Bespoke Signal Mapping utilises digital signal processing to apply tailored crossover filters that are designed specifically for each configuration of drive units within a loudspeaker.
E3 Bass
Meridian E3 Bass uses specifically designed filters to expand, extend and enhance the low-frequency response of the loudspeaker.
FFA
FFA (Full Frequency Alignment) is a combination of digital filters and delays to correct the group-delay of a loudspeakers. It ensures that all frequencies reach the listener’s ear at the same time.
Pro-Active Bass
Meridian Pro-Active Bass protects the bass drivers from over-excursion, ensuring maximum bass output without damaging the drive units.
Pro-Active Thermal
Meridian Pro-Active Thermal monitors the audio being sent to the mid-range drivers and tweeters and limits the overall volume of the loudspeaker if there is a risk of the drive units getting too hot.
Q-Sync
Meridian Q-Sync deploys Meridian's multiple “First In, First Out” buffering system which minimizes jitter, ensuring perfect timing and improved clarity.
True Time
True Time is Meridian's proprietary Anodizing Filter that avoids pre-ringing and cleans up the effects of early filters, converting pre-echo to post-echo.
True Link
Meridian True Link is an encryption method for transferring high-definition digital audio over SPDIF connections. It allows secure movement of digital audio whilst ensuring that the SPDIF clock signal can be transmitted with minimum degradation.
Meridian True Time
After painstaking research, Meridian developed a special filter that avoids pre-ringing, so it can be steeper, cleaning up the effects of early filters.
The Special Edition Loudspeakers
Meridian’s goal has always been to reproduce the sound of the original performance exactly, and let nothing else get in the way.
Special Edition Loudspeakers
Provides accurate time alignment of the drivers in the system, delivering exceptional imaging and a clearm transparent, more life like sound.
Meridian Special Edition Loudspeakers.mp4 from Meridian Audio on Vimeo.
Audio Inputs
Meridian SpeakerLink (RJ45) & RCA phono digital inputs accepting 32kHz to 96kHz sampling rates at up to 24-bit
Audio Outputs
Meridian SpeakerLink (RJ45) & RCA phono digital outputs delivering 32kHz to 96kHz sampling rates at up to 24-bit
Performance
Peak SPL: 118dB at 1m (music material)
Noise less than 15dB SPL
Frequency response in-room within 3dB: 30Hz to over 32kHz
Amplifiers
4 x 150W (600W)
Overall distortion typically <0.02% at any frequency or level
Bass Drivers
2 x 200mm long-throw
Mid Driver
160mm polypropylene
Beryllium Dome Tweeter
25mm (1”) Meridian piston in short-horn, beryllium dome with silver voice-coil
Display
Eight character display with additional status indicators; can be blanked in use
Dimensions / Weight
HEIGHT: 295mm [11.6in]
WIDTH: 1060mm [41.7in]
DEPTH: 478mm [18.8in] (At deepest point)
WEIGHT: 64kg [141lbs]
Power
17VA standby; 920VA max
